BossBoss DD3 Digital Delay
BOSS DD-3 Digital Delay brings the familiar sound and simple operation of the classic DD-3 into a modern pedal with useful performance features. It provides delay times from 12.5 to 800 ms, with three ranges for quick setup. Tap tempo can be controlled from the onboard pedal switch or an optional external footswitch, with three selectable subdivisions. The Short Loop function lets you capture and repeat a phrase of up to 800 ms while you play over it. A dedicated Direct Out also supports wet/dry setups by allowing delayed and dry signals to be sent separately. With straightforward controls, buffered bypass and a compact BOSS pedal format, the DD-3 is a practical digital delay for guitarists who want reliable delay sounds without unnecessary complexity.
SPECIFICATIONS
| Nominal Input Level | -20 dBu |
| Input Impedance | 1 M ohm |
| Nominal Output Level | -20 dBu |
| Output Impedance | 1 k ohm |
| Recommended Load Impedance | 10 k ohms or greater |
| Bypass | Buffered bypass |
| Controls | MODE knob TIME knob FEEDBACK knob E.LEVEL (Effect Level) knob Pedal switch |
| Indicator | CHECK indicator (Used for indication of check battery) |
| Connectors | INPUT jack: 1/4-inch phone type OUTPUT jack: 1/4-inch phone type DIRECT OUT jack: 1/4-inch phone type TEMPO jack: 1/4-inch phone type DC IN jack |
| Power Supply | Alkaline battery (9 V, 6LR61) AC adaptor (PSA series: sold separately) |
| Current Draw | 70 mA |
| Expected Battery Life Under Continuous Use | Alkaline: Approx. 5 hours These figures will vary depending on the actual conditions of use. |
| Accessories | Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information") Alkaline battery (9 V, 6LR61) |
| Options (Sold Separately) | AC adaptor: PSA series Footswitch: FS-5U, FS-6, FS-7 |
| Width | 73 mm| 2-7/8 inches |
| Depth | 129 mm | 5-1/8 inches |
| Height | 59 mm | 2-3/8 inches |
| Weight (Including Battery) | 420 g | 15 oz |
