BossOC-5 Exp Octave Guitar Effects
Show all:
Octave,Accessories
Trade-ins Welcome
Beginner to Pro Friendly
Fast & Reliable Delivery
Secure Online Shopping
Description
Read moreRead less
The Boss OC-5 Exp Guitar Effects pedal delivers precise octave effects for both guitar and bass. Its advanced tracking technology provides fast, natural response with minimal latency. Vintage mode reproduces classic mono octave sounds, while Poly mode handles chords with selectable note ranges. The pedal adds a new octave-up effect, which can be blended with octave-down tones or used alone. A mode switch optimizes the effect for guitar or bass, and the direct out supports wet/dry setups. Built for stage and studio use, the OC-5 offers reliable performance with BOSS durability and a five-year warranty.
SPECIFICATIONS
| Nominal Input Level | -20 dBu |
| Input Impedance | 1 M ohm |
| Nominal Output Level | -20 dBu |
| Output Impedance | 1 k ohm |
| Recommended Load Impedance | 10 k ohms or greater |
| Bypass | Buffered bypass |
| Controls | Pedal switch, GUITAR/BASS switch, VINTAGE/POLY switch, DIRECT LEVEL knob, +1OCT knob, -1OCT knob, -2OCT/RANGE knob |
| Indicator | CHECK indicator (Serves also as battery check indicator) |
| Connectors | INPUT jack: 1/4-inch phone type OUTPUT jack: 1/4-inch phone type DIRECT OUT jack: 1/4-inch phone type DC IN jack |
| Power Supply | Alkaline battery (9 V, 6LR61 or 6LF22) AC adaptor (PSA series: sold separately) |
| Current Draw | 60 mA |
| Expected battery life under continuous use | Alkaline: Approx. 5 hours *These figures will vary depending on the actual conditions of use. |
| Accessories | Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information") Alkaline battery (9 V, 6LR61) |
| Options (sold separately) | AC adaptor: PSA series |
| Width | 73 mm | 2-7/8 inches |
| Depth | 129 mm | 5-1/8 inches |
| Height | 59 mm | 2-3/8 inches |
| Weight | 440 g | 1 lb |
