CitronicCMC-14 Live Mixing Console
Show all:
Session Mixers,Pro Audio
Trade-ins Welcome
Beginner to Pro Friendly
Fast & Reliable Delivery
Secure Online Shopping
Description
Read moreRead less
The Citronic CMC-14 Live Mixing Console helps you control your sound in one place. You can connect microphones, instruments, and music devices easily. Each channel lets you adjust the sound to make it clearer and balanced. The built in effects help improve vocals and add depth. You can play music using Bluetooth or record using USB. It also works with a computer for recording or streaming.
SPECIFICATIONS
| Weight | 3.30kg |
| Dimensions | 345 x 310 x 80mm |
| Inputs : Mic/Line | 6 x XLR / 6.3mm jack |
| Power Supply | 100-240Vac, 50 / 60Hz (IEC) |
| Fuse | T1.6AH |
| Effects | 99 program DSP (2 parameter controls) |
| Inputs : Line | 2 x stereo L + R 6.3mm, stereo RCA + stereo 3.5mm |
| Audio Source | Bluetooth receiver, USB mp3 player / recorder |
| Bluetooth Version | v5.1 (+BR + EDR + BLE) |
| EQ : Low | ±15dB @ 80Hz |
| EQ : Mid | ±15dB @ 2.5kHz |
| EQ : High | ±15dB @ 12kHz |
| Phantom Power | +48V switchable in pairs (XLR inputs only) |
| Frequency Response | 20Hz - 22kHz (±1dB) |
| Input Level | Mic +10dBu max. / Line +22dBu max. |
| Input Impedance | Balanced XLR 2k Ohm, Balanced TRS jack 10k Ohm (unbal 20k Ohm) |
| THD + N | <0.05% @ 1kHz |
| Noise | EIN -122dBu (22Hz - 22kHz) |
| CMRR | >75dB (Mic 1kHz) |
| Sensitivity | XLR -60 to +10dBu, TRS jack -20 to +20dBu, Stereo -20 to +14dBu |
| Crosstalk | >80dB (1kHz fader shutoff) |
| Outputs | Main L + R XLR, L + R Monitor 6.3mm, Headphones 6.3mm |
| Max. Output Level | XLR +22dBu, TRS +20dBu |
| Sends : Returns | 1 Aux send, L + R return |
